NEX QC+ QuantEZ
The NEX QC+ QuantEZ: Benchtop EDXRF Elemental Analyser is a powerful, user-friendly benchtop XRF analyser for precise elemental analysis across a wide range of samples.
Product Overview
The Rigaku NEX QC+ QuantEZ system is NEX QC+ at its core but packaged with powerful QuantEZ software operating from an external PC. This instrument provides easy operation with a simple menu navigation and a customizable EZ Analysis screen. This screen’s flow bar wizard gives a step-by-step setup, walking users through creating their own methods.
Compared to the NEX QC and NEX QC+ models, NEX QC+ QuantEZ expands the analytical capabilities and range of applications with the availability of RPF-SQX Fundamental Parameters. This software option reduces the need for standards, which can be expensive and difficult to obtain for many applications. Additional software options are also available, including SureDI, supporting compliance with 21 CFR Part 11. This option allows organizations in regulated industries, such as pharmaceuticals, to meet FDA requirements confidently.
Features & Benefits
Intuitive QuantEZ Software
Superior SDD Detector Precision
Flexible Automated Tube Filters
Key applications
• Non-destructive elemental analysis for sodium (Na) to uranium (U)
• Powerful and easy-to-use QuantEZ software with multilingual user interface
• Solids, liquids, alloys, powders and thin films
• 50 kV X-ray tube for wide elemental coverage
• Silicon drift detector (SDD) for superior resolution
• Multiple automated tube filters for enhanced sensitivity
• Unmatched performance-to-price ratio
• Advanced RPF-SQX Fundamental Parameters software
• SureDI support for 21 CFR Part 11 compliance
NEX QC+ QuantEZ Product Video
About the NEX QC+ QuantEZ
Introducing the NEX QC+ QuantEZ EDXRF Analyser, Rigaku’s recent innovation in benchtop ED-XRF elemental analysis.
This advanced analytical instrument is designed to meet the growing demands of modern laboratories for fast, accurate, and reliable elemental analysis.
The analyser leverages the power of Energy Dispersive XRF Technology, offering an unparalleled analysis range from Aluminium to Uranium, catering to a broad spectrum of materials, including solids, liquids, and thin films.
At the heart of the NEX QC+ lies the QuantEZ software, a game-changer in XRF analysis. This software simplifies the complexity of XRF analysis, allowing users of all levels to achieve accurate results with minimal training. The software’s intuitive interface guides users through the application set up, making sophisticated XRF analysis accessible to everyone.
The inclusion of a state-of-the-art Silicon Drift Detector (SDD) ensures that the NEX QC+ delivers exceptional sensitivity and resolution across the entire elemental range.
This, combined with automated tube filters, allows for optimised analysis conditions for each element, ensuring precise and accurate results every time. The NEX QC+ is not just about performance; it’s also designed with the user in mind.
Its compact footprint and low-cost operation make it an ideal solution for laboratories looking to expand their analytical capabilities without extensive space or budget.
| Technique | Direct excitation energy dispersive X-ray fluorescence (EDXRF) | |
|---|---|---|
| Benefit | Combines performance and affordability; elemental analysis of solids, liquids, powders, alloys, and thin films | |
| Technology | EDXRF using a high-performance SDD | |
| Attributes | 50 kV 4 W X-ray tube, high-performance SDD, embedded computer, icon-driven graphical user interface, built-in printer, USB and Ethernet connections, analyze Na to U | |
| Options | Helium purge, automatic sample changer, single-position sample spinner, UPS, portable carrying case | |
| Dimensions | 331 (W) x 376 (H) x 432 (D) mm | |
| Mass | Approx. 16 kg | |
| Power requirements | 1Ø, 100 – 240 V, 1.4 A (50/60 Hz) | |
"The QUANTEZ by Rigaku revolutionizes EDXRF analysis, offering superior precision
and speed in elemental determination across diverse applications."
Product FAQ's
Its integration with QuantEZ software and the advanced SDD detector offers unmatched ease of use and precision.
Yes, it can accurately analyse light elements, thanks to its high sensitivity and automated tube filters.
Minimal training is needed due to the intuitive QuantEZ software, making it accessible for users of all skill levels. User training is always included with every instrument.
Through its superior SDD detector, automated tube filters, and optimised analysis conditions for each element.
Absolutely, its versatility and precision make it suitable for a wide range of applications, from research to industrial quality control.
Applications
Application Note 1
Application Note 2
Application Note 3
